Sintoamplificador
A / V 7.2 para Home Theater
• 7-channel
powerful surround sound (1,330W=190W x 7 max for Europe;
910W=130W x 7 RMS; 1,330W=190W x 7 max)
• HD Audio format decoding: Dolby TrueHD and DTS-HD Master Audio;
Dolby Digital Plus and DTS-HD High Resolution Audio
• H-shape cross member frame and rigid bottom frame
• Symmetrical power amplifier layout
• New heat sink with anti-vibration and anti-thermal properties
• High speed thermal feedback power amplifier
• DAC on Pure Ground circuitry with high quality Burr-Brown PCM1789
DACs
• Ultra Low Jitter PLL circuitry
• Intelligent Assignable amplifiers for bi-amp or Surround Back
- Front Presence or Zone 2/Zone 3 connection
High Picture Quality
• Analogue
and HDMI video upscaling to full HD 1080p
• 1080p-compatible HDMI: 8 inputs (1 on front) and 2 outputs
(simultaneous)
• Supports Deep Colour (30/36 bit), x.v.Colour, 24Hz Refresh
Rate and Auto Lip-Sync compensation
•
HQV high-class chipset “VHD1900” for HD/SD Video
• Video adjustment functionality
— New auto noise reduction (mosquito noise, block noise, temporal
noise)
— New auto resolution enhancement (detail/edge enhancement)
— Video signal control (Contrast, Brightness, Saturation)
— 6 preset memories
Advanced Features
• New SCENE
PLUS - simple and versatile functionality
-12 SCENE choices (4 on front panel and others on GUI)
-Zone SCENE - 4 SCENE buttons for Zone 2/Zone 3
-Versatile parameters can be stored into each SCENE
• Network functions
-Access to Internet Radio (MP3/WMA) and music files on PC or
DLNA Server (WAV, MP3, WMA, AAC, FLAC 96/24)
-Web Browser Control via PC or PDA
-Receiver Manager through network connection
-DLNA 1.5 certified
• YPAO-R.S.C. (Reflected Sound Control) sound optimisation with
multi-point measurement
— DSP Effect Normalization
— Room Acoustic Echo
— Controlling reflection and echo
• HDMI (V.1.4a with 3D and Audio Return Channel)
• HDMI CEC functionality
• New on-screen display GUI with album art and 6 languages (English,
French, German, Spanish, Russian and Japanese)
• Flexiblly assignable component video and optical/coaxial (except
Video Aux) inputs allow a wide range of source coponents
• Video Adjustment Preset
• Ability to change HDMI input while in Standby Through mode
• USB port for portable audio players and flash drives (MTP/MSC)
• iPod/iPhone compatibility with optional YDS-12 Universal Dock
• iPod song titles displayed in English and Western European
languages on the front panel and on-screen display
• Wireless connection for iPod/iPhone with optional YID-W10
•
Bluetooth (A2DP) compatibility with optional Yamaha Bluetooth® Wireless
Audio Receiver YBA-10
• Dialogue Lift
• Auto power down function with variable time setting
Surround Realism
• HD Audio
decoding with CINEMA DSP 3D (23 DSP programmes)
• Compressed Music Enhancer with CINEMA DSP
• Virtual Presence Speaker function for CINEMA DSP 3D surround
without Front Presence Speakers
• Channel expandability with external amplifier (9-channel expandability
(bi-amping))
• Adaptive DRC (Dynamic Range Control) and Adaptive DSP Level
Versatile Zone Control
• Zone 2/Zone
3 on/off and control on front panel
• Zone GUI (song/station selection, album cover art display,
zone tone controls/Zone balance, short message)
• Zone video assign (Zone 2/Zone 3)
• System Backup / Recovery function
• Multi-channel output in main zone plus 2-channel HDMI output
in a second zone
• Zone MONO, Zone volume and tone controls
• Party mode
