| Drivers |
LF: 135 mm (5.25 in) low frequency loudspeaker
HF: 19 mm (.75 in) Polycarbonate dome tweeter |
| Frequency Range |
80 Hz - 20 kHz |
| Amplifier Power Rating |
35 Watts |
| Maximum SPL (1m) |
111 dB |
| Frecuencia de crossover |
4.2 kHz |
| Input Sensitivity |
+4 dBu XLR 1/4"; 0 dBu RCA |
| CONEXIONES DE ENTRADA |
Balanced Neutrik®* Combo XLR 1/4" TRS; Unbalanced RCA |
| Power Requirements |
19 VDC / 3.42 A - use only supplied power supply |
| Headphone Jack |
3.5 mm (1/8") |
| Dimensions (H x W x D) |
235 x 159 x 143 mm (9.3 x 6.3 x 5.6 in) |
| Net Weight (each) |
2.6 kg (5.5 lb) |
| Grille |
Zinc-plated steel |
| Mounting Hardware |
Optional |
| Included Accessories |
Speaker wire, power supply, 2 snap-on pedestals. |
| Optional Accessories |
MTC-2P Mounting Kit (2 brackets, power supply holder) |
| |
* Neutrik and the names of Neutrik products referenced herein are either trademarks and /or service marks
of Neutrik. |
| LF Driver |
5.25in (135 mm) |
| LF Driver Power Handling |
35 Watts per channel |
| RESPUESTA DE FRECUENCIA (±3 dB) |
100 Hz – 18 kHz |
| Maximum Peak SPL |
111 dB |
| Enclosure |
Polypropylene Structural Foam |
| Coverage Angle |
120°H x120°V |
